Characteristic:
‧ Shock absorbers for shock absorbers in windmills are easy to install.
‧ cushioned stainless steel mesh design to overcome impact vibration
‧ The spring is made of imported steel wire, and after special heat treatment, it has excellent isolation effect.
‧ It can isolate the noise transmitted by the mechanical vibration and achieve the purpose of soundproofing.
Application:
‧ Dedicated to the internal wall of the air conditioning box.
‧ Miniature exhaust fans and windmills
‧ Small ice water units and water pumps
model | Load range Kg | Coefficient of elasticityKg/mm | Applicable deflection mm | Spring color |
ME-020 | 10-20 | 0.8 | 25 | yellow |
ME-030 | 20-40 | 1.2 | 25 | green |
ME-050 | 40-60 | 2.0 | 25 | red |
ME-070 | 60-80 | 2.8 | 25 | blue |
ME-090 | 80-100 | 3.6 | 25 | brown |
ME-120 | 100-130 | 4.8 | 25 | gray |
ME-150 | 130-160 | 5.6 | 25 | White |
ME-180 | 160-190 | 6.4 | 25 | Orange |
ME-250 | 190-220 | 7.2 | 25 | black |
ME-350 | 220-250 | 8.0 | 25 | Yellow |
